I have some joy today as I’ve returned to a line of research. This will be a quick memo blog. The first part ended with this blog. http://probersideas.blogspot.com/2010/06/new-field-of-research.html
The Changes
I made some major changes in my systems just to return to this matter. First to go, was the Gen3 electronics. In hindsight I couldn’t recommend them to anyone. IMHO, they suffer from EMI issues, among in general being a poor design.
Next to go was the PTFE insulator. I’ve replaced the hot end with a peek only compact hot end from MakerGear.
more to come in 2.0
Saturday, January 15, 2011
Monday, January 3, 2011
The Jury isn’t out
In 2010 the community received a wake up call in the Up printer. It wasn’t rocket science that was the wake up call. The basic ideas and concepts of the UP printer were all out there. It took the Up designers to fine tune the ideas into a project.
Parts of the community have learned from the UP printer. Quality and speed don’t have to be sacrificed for production.
2011 brings with it the hopes of continuous improvements in quality, and speed for our Repraps.
While some have come to dismiss the Prusa Mendel, they miss many of the features that make this simple design worthy of replacing the “Classic” Mendel. Let’s face the facts; the “Classic” Mendel is now an old design of 2008-09. The Prusa Mendel moves us forward late 2010 forward.
While many continue to argue the merits of the “Classic” Mendel vs the Prusa Mendel, they just need to catch up to the moving front, as the Jury has come back in. The replacement for the “Classic” Mendel is the Prusa Mendel.
Parts of the community have learned from the UP printer. Quality and speed don’t have to be sacrificed for production.
2011 brings with it the hopes of continuous improvements in quality, and speed for our Repraps.
While some have come to dismiss the Prusa Mendel, they miss many of the features that make this simple design worthy of replacing the “Classic” Mendel. Let’s face the facts; the “Classic” Mendel is now an old design of 2008-09. The Prusa Mendel moves us forward late 2010 forward.
While many continue to argue the merits of the “Classic” Mendel vs the Prusa Mendel, they just need to catch up to the moving front, as the Jury has come back in. The replacement for the “Classic” Mendel is the Prusa Mendel.
Sunday, December 19, 2010
Quick Temperature Hack
One frustration with Reprap for me has been the fragile nature of the beast. Seems like I get one item fixed another item breaks on me. Such was the case with my thermistor.
I had rebuilt my hot end, and had my thermistor taped to the nozzle and it generally worked. Thought I had gotten up and running again, then the thermistor failed on me. It was my last one and I had a supply on order.
The problem I realized was getting readings off the nozzle itself.
The wires would get twisted among other issues I had with it. A better way had to be found with the materials at hand.
I attempted to take two washers and make a temp reading washer. It just didn't work right.
Failure
I had rebuilt my hot end, and had my thermistor taped to the nozzle and it generally worked. Thought I had gotten up and running again, then the thermistor failed on me. It was my last one and I had a supply on order.
The problem I realized was getting readings off the nozzle itself.
The wires would get twisted among other issues I had with it. A better way had to be found with the materials at hand.
I attempted to take two washers and make a temp reading washer. It just didn't work right.
Failure
Then it hit me, the trusty Paperclip. The more I played with the idea the more ideal this became for a quick temperature hack or more.
The Trusty PaperClip
It can be reused, it’s modular
Can be turned to adjust the wires
The nozzle can be changed with no issues
Working Parts
All you need to do is pick the right size paperclip for your hot end.
Bonus!!! Need to see if your temp is working? Turn on your software and put your two fingers on the end of the paperclip and you will shortly find out if it’s working or not.
How it works
The small end of the Paperclip acts like a nut and can be screwed down to any level needed. Just make sure you use plenty of tape.
Wires Wrapped
Make sure the wires are fully wrapped as you don’t need any contact or shorts.
Finish Wrap
Finish wrapping the glass bead so you have one complete, taped up device.
Placement
Lock in the glass bead leaving the small space at the Paperclip top, to be used as a locking means.
Finished.
Finish off the device by taping down the locked in glass bead. You’re all done.
TEST
You are ready to test.
Monday, November 8, 2010
Whistles for Josef A RepRap Action.
Repost of the Blog by Rick Pollack
"Josef Prusa - the Prusa in the Prusa Mendel - is giving a presentation at the TedX event in Prague on November 20th. He is printing 300 whistles to hand out to the attendees but he is up against the clock.
If you have the technology to print some whistles and you can have them in Prague by the 20th...let me know and I'll get you the shipping address..."
Update: Link to more info: How to send a whistle
Thursday, November 4, 2010
3D Printed Cars & MDAR bots for Area 51
Couple of news stories that might be of interest ….
3D Printed Cars May Be the Way of the Future and MDAR the new bots for Area 51 etc.
"Urbee, a two passenger car, is being designed by Kor Ecologic Inc., using Stratasys 3D printers. Kor Ecologic probably chose Stratasys because their printers are considered cheap and reliable; I know that they're reliable because I have seen them myself and I know what they can make. But cheap? If you consider a $14,900 cheap for a small printer, then sure, why not, but I can't imagine how much a large 3D printer capable of printing car parts could cost!"
==================================
Robots Invade Nevada National Security Site
"And it's in this spirit of optimism -- some might say naivete -- that technical whizbangs working for the Nevada National Security Site, formerly known as the Nevada Test Site, have unveiled the MDARS, short for Mobile Detection Assessment Response System. Call them what you want, they're robots. And they are now on the job patrolling sensitive parts of the sprawling desert facility.
"It thinks on its own, and in that regard it doesn't require the constant plume of intervention," said NNSA senior engineer Steve Scott."
3D Printed Cars May Be the Way of the Future and MDAR the new bots for Area 51 etc.
"Urbee, a two passenger car, is being designed by Kor Ecologic Inc., using Stratasys 3D printers. Kor Ecologic probably chose Stratasys because their printers are considered cheap and reliable; I know that they're reliable because I have seen them myself and I know what they can make. But cheap? If you consider a $14,900 cheap for a small printer, then sure, why not, but I can't imagine how much a large 3D printer capable of printing car parts could cost!"
==================================
Robots Invade Nevada National Security Site
"And it's in this spirit of optimism -- some might say naivete -- that technical whizbangs working for the Nevada National Security Site, formerly known as the Nevada Test Site, have unveiled the MDARS, short for Mobile Detection Assessment Response System. Call them what you want, they're robots. And they are now on the job patrolling sensitive parts of the sprawling desert facility.
"It thinks on its own, and in that regard it doesn't require the constant plume of intervention," said NNSA senior engineer Steve Scott."
Thursday, October 7, 2010
First Impressions Gen6 Electronics
This morning I was handed a set of the new Gen6 Electronics manufactured in the Netherlands by Mendel parts.com
I haven’t written much lately, and frankly this new “gift” to the RepRap community forced me to make the time available.
Most of the time I don’t like to buy electronic items on the first run. I like to buy when items come down in price, and have any bugs taken care of. When I reviewed the hype (in hindsight), of Generation 3 electronics I thought that I was buying a mature, bug free design. I’m going to be kind to MBI here and just say “not as advertised”.
At first look, Gen6 electronics truly can be advertised as “plug and play”. I will know much better when I hook everything up and start running.
Pics from the web site just don’t do this set justice. We are talking a quality board here. Just new I had to take some quick pics, and show the community what they haven’t seen yet.
I love when a product has some thought given to it. Truly, the optics are a Gem! Who ever thought of the endstop optics design, needs to be given real thumbs up! No fiddling around with solder, just plug and play, the real thing.
From these pics you can see its very comfortable size compared to a standard Gen3 extruder board..
Front and Back sides.
To sum up my first impressions; Gen6 is everything Gen3 should have been!
I haven’t written much lately, and frankly this new “gift” to the RepRap community forced me to make the time available.
Most of the time I don’t like to buy electronic items on the first run. I like to buy when items come down in price, and have any bugs taken care of. When I reviewed the hype (in hindsight), of Generation 3 electronics I thought that I was buying a mature, bug free design. I’m going to be kind to MBI here and just say “not as advertised”.
At first look, Gen6 electronics truly can be advertised as “plug and play”. I will know much better when I hook everything up and start running.
Pics from the web site just don’t do this set justice. We are talking a quality board here. Just new I had to take some quick pics, and show the community what they haven’t seen yet.
I love when a product has some thought given to it. Truly, the optics are a Gem! Who ever thought of the endstop optics design, needs to be given real thumbs up! No fiddling around with solder, just plug and play, the real thing.
From these pics you can see its very comfortable size compared to a standard Gen3 extruder board..
Front and Back sides.
To sum up my first impressions; Gen6 is everything Gen3 should have been!
Tuesday, August 3, 2010
A wake up call !
I was shocked this morning when I opened my email.
Let me digress for a moment to tell the story.
I’ve been on my quest to get a decent RepRap going. Seems each time I turn around Its another patch up job or a visit to the local hardware store (they know me now). With no Reprap parts available you have to “innovate” and make your own hacked up fixes.
Sometimes you get to the point of no return. You must ask for others for help as only a new printed RP part will do the job> Only way to make all the other hacks work. This was my case; I had a hacked up revised extruder that worked. Only problem, the Darwin x carriage would not do the job. It only had a very small dc motor on it, just couldn't handle the small weight. You see the part was an early Cast Reprap made out of Polyurethane. I’ve learned so much since I bought it.
Anyhow, I tried Emailing for some help to print out some parts. The end result would bring some much need strength into the project. Some people said they would help and never would reply to again to the emails. Some offered to build for a cost, no problem if it wasn’t an arm and a leg, I would have gone for it. In the end nothing came of it. With all the users in the community out there my only hope turned to posting in the forums. http://forums.reprap.org/read.php?95,51778 Posted on 7/15/2010,
Up until the time of this blog posting, not one email, or contact has come from that post. That was until today’s surprise email.
See a new firm with the UP Printer http://www.pp3dp.com/ just released a new 3DPriter to the Reprap community. They had an offer that I thought might be great to try.
http://pp3dp.com/index.phpoption=com_content&view=category&layout=blog&id=42&Itemid=56
Step 3. If you kindly provide your input to all the questions in the survey, we are willing to mail your 3D model to you only for the cost of mailing for our appreciation of your feedback.
So I looked up the old STL, done in AOI I believe, and sent off an email to them This was in late afternoon for me. Like many of the firms now days, I expected some game, or to be ignored as in my past experiences. To my shock in this mornings email
I received these beautiful jpegs. This UP printer firm means business, and is building good will!
Side note: I may have gotten lucky. Reviewing the jpeg’s shows that the reinforcements in the UP software have made one of the best,if not the Best Darwin x-carriages ever repraped.
Let me digress for a moment to tell the story.
I’ve been on my quest to get a decent RepRap going. Seems each time I turn around Its another patch up job or a visit to the local hardware store (they know me now). With no Reprap parts available you have to “innovate” and make your own hacked up fixes.
Sometimes you get to the point of no return. You must ask for others for help as only a new printed RP part will do the job> Only way to make all the other hacks work. This was my case; I had a hacked up revised extruder that worked. Only problem, the Darwin x carriage would not do the job. It only had a very small dc motor on it, just couldn't handle the small weight. You see the part was an early Cast Reprap made out of Polyurethane. I’ve learned so much since I bought it.
Anyhow, I tried Emailing for some help to print out some parts. The end result would bring some much need strength into the project. Some people said they would help and never would reply to again to the emails. Some offered to build for a cost, no problem if it wasn’t an arm and a leg, I would have gone for it. In the end nothing came of it. With all the users in the community out there my only hope turned to posting in the forums. http://forums.reprap.org/read.php?95,51778 Posted on 7/15/2010,
Up until the time of this blog posting, not one email, or contact has come from that post. That was until today’s surprise email.
See a new firm with the UP Printer http://www.pp3dp.com/ just released a new 3DPriter to the Reprap community. They had an offer that I thought might be great to try.
http://pp3dp.com/index.phpoption=com_content&view=category&layout=blog&id=42&Itemid=56
Step 3. If you kindly provide your input to all the questions in the survey, we are willing to mail your 3D model to you only for the cost of mailing for our appreciation of your feedback.
So I looked up the old STL, done in AOI I believe, and sent off an email to them This was in late afternoon for me. Like many of the firms now days, I expected some game, or to be ignored as in my past experiences. To my shock in this mornings email
I received these beautiful jpegs. This UP printer firm means business, and is building good will!
Side note: I may have gotten lucky. Reviewing the jpeg’s shows that the reinforcements in the UP software have made one of the best,if not the Best Darwin x-carriages ever repraped.
